Onkyo TX-RZ830

51
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
 7.1.2 Channel System
12
9bk
5 4
87
3
6
This is a combination of the 7.1 Channel System and front high speakers. A front high speaker is a type of height speaker.
You can select only one set of height speakers from the following three types for connection.
❏ Front High Speakers/Rear High Speakers Installation Example ( p21)
❏ Ceiling Speakers Installation Example ( p22)
❏ Dolby Enabled Speakers (Dolby Speakers) Installation Example ( p23)
 "Speaker Setup" settings during
Initial Setup ( p157)
Speaker Setup
< >
Speaker Channels
Subwoofer
Height 1 Speaker
Height 2 Speaker
Zone Speaker
Bi-Amp
7.1.2 ch
Yes
Front High
---
No
No
Select how many speakers you have.
Next
• Speaker Channels: 7.1.2 ch
• Subwoofer: Yes
• Height 1 Speaker: Select the type of
height speaker actually installed.
• Height 2 Speaker: ---
• Zone Speaker: No
• Bi-Amp: No
