PRINTED CIRCUIT BOARD VIEWS-3
TX-SR504/504E/8450
Component side Soldering side
U02
TRANS SEC. TERMINAL PC BOARD (NAPS-8780)
Component side
U03
THERMAL SENSOR PC BOARD (NAETC-8781)
A
1
2
3
4
5
BCD
