Onkyo TX-SR875 - Exploded View Parts List; Notes on Parts

TX-SR875
<Note>
1.Parts marked b
y
"NSP" are
g
enerall
y
unavailable because
the
y
are not in our Master S
p
are Parts List.
2.ICs marked b
y
"NRP" are not re
p
laceable because some
p
ins
on bottom are unable to see and solder..
<Notes>
(
B
)
: TX-SR875 Black mode
l
<DC> : TX-SR875 USA and Canadian model
(
G
)
: TX-SR875 Golden model <DT> : TX-SR875 Asian model for 120V
(
S
)
: TX-SR875 Silver model <MP> :TX-SR875 Euro
p
ean model
<MB> : TX-SR875 UK model
[
U
]
: Made in Ja
p
an <MT> : TX-SR875 Asian model for 220V
[
M
]
: Made in Mala
y
sia <MK> : TX-SR875 Korean model
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'T
Y
PART NO.
(
SN
)
REMARKS
A001 HEAT SINK . 2 27160603A [U]
A001 HEAT SINK . 2 27160603B [M]
A004 ISO PLT (HS) 1 28175334
A005 SPACER (PC) 8 27270485
A007 SCREW 3P+6FN(3BC) 8 82143006GR
A008 SCREW 3TTB+8B(3CM)SR 79 801637
A009 SCREW 3SMS8W.SW+14B(CU) 28 801634
A011 RETAINER (HS-2) 2 27141530A
A013 SCREW 3TTB+8B(3CM)SR 4 801637
A014 SPACER t0.5x8x3.2 3 27270438
A015 CHASSIS (SUB) 1 --- NSP
A018 CUSHION (T3*W35*D10) 1 28141741
A020 CUSHION t10*10*100 1 28141746
A021 BUTYL 3(5m) 1 WS3628 [U]
A021 CUSHION (BUTYL) 1 28141748 [M]
A022 TAPE TAPE(CLOTH-8U) 1 29110082
A024 BUTYL φ3(5m) 1 WS3628 [U]
A024 CUSHION (BUTYL) 1 28141748 [M]
A025 HEAT SINK(S) 240 1 27160608
A030 ISO PLT (AMP2) 1 28175333
A031 RIVET P-RIVET NRP-345 2 880009
A032 CUSHION T5*8*8 2 28141742
A033 ISO PLT (AMP) 1 28175331A
A038 ISO PLT (FFC) 1 28175332
A039 PLA RIVET P3035B 2 880016
A040 BRACKET (FAN-L) 1 27131022A
A042 HOLDER (FAN) 4 27191307
A044 BRACKET (FAN-R) 1 27131023A
A046 HOLDER (FAN) 4 27191307
N
OTE : THE COMPONENTS IDENTIFIED BY THE MAR
K
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
