Ootori RM503 - Names and Functions of Parts; Main Unit

11
12
Place the seat onto the seat and attached it with Velcro tapes, and connect
Connect the cabel and air plugs of seat with seat cushion.
Insert the power plug and the data line of the controller into their outlet.
Set the power switch to the "on" position, the power indicator lights up.
NAMES AND FUNCTIONS OF PARTS
MAIN UNIT
1.Pillow
2.Backpad
3.Forearm Units
4.Heater
5.Seat
6.Seat Vibrator
7.Footrest
8.Armrest
9.Shoulder Units
10.Air Vent
11.Specification Label
12.Power Supply
13.Wheels
14.Power Switch
15.Electrical Fuse
16.Cord Connector
10
11
12
13
15 14 16
09 10
1
2
3
4
5
6
7
8
9
