Openpath OP-16EM - Page 22





Figure 15: Wiring to Legacy Panels

WARNING: Do not connect 12V out on the Wiegand port to the legacy panel;
doing this will cause voltage backfeeding, potentially damaging one of the
supplies.

 

Version 1.8
© Openpath 2020
Page 22

