Warnings in these operating instructions are placed in front of an instruction that may result in personal
injury or property damage.
Measures to avert a hazard must be observed.
Warnings in these operating instructions are placed in front of an instruction that may
result in personal injury or property damage.
Measures to avert a hazard must be observed.
WARNING
SIGNS
MEANING
Warning of a danger spot !
Indicates potentially dangerous situations. Failure to observe the
warn
ing notices may result in personal injury and/or damage to
property.
Warning of dangerous voltage!
Indicates possible hazards due to electricity. Failure to observe the
warnings may result in death, injury and/or property damage.
Warning of hot surface !
Indicates possible hazards due to high surface temperatures.
Failure to observe the warnings may result in personal injury and/or
damage to property.
Warning of hand injuries !
Indicates possible hazards due to moving and rotating parts. Non-
observance of the warnings can result in personal injury.
Warning of toxic substances !
Indicates possible dangers due to inhalation of toxic gases. Failure to
observe the warnings may result in death or serious poisoning.
Warning of flammable substances !
Indicates possible dangers due to fire hazard. Failure to observe the
warnings may result in death, personal
injury or property damage.
Warning of cuts due to glass breakage !
Indicates possible hazards due to sharp edges. Failure to observe the
warnings may result in cutting injuries and personal injury.
3
EN
WARNING NOTICE AND SYMBOLS
Warning of a danger spot!
Indicates potentially dangerous situations. Failure to observe the warning notices
may result in personal injury and/or damage to property.
Warning of dangerous voltage!
Indicates possible hazards due to electricity. Failure to observe the warnings may
result in death, injury and/or property damage.
Warning of hot surface!
Indicates possible hazards due to high surface temperatures.
Failure to observe the warnings may result in personal injury and/or damage to
property.
Warning of hand injuries!
Indicates possible hazards due to moving and rotating parts. Nonobservance of the
warnings can result in personal injury.
Warning of toxic substances!
Indicates possible dangers due to inhalation of toxic gases. Failure to observe the
warnings may result in death or serious poisoning.
Warning of flammable substances!
Indicates possible dangers due to fire hazard. Failure to observe the warnings may
result in death, personal injury or property damage.
Warning of cuts due to glass breakage!
Indicates possible hazards due to sharp edges. Failure to observe the warnings may
result in cutting injuries and personal injury.
Tr
ansport, unpacking, setting up
If the device is brought from a cold environment into the operating room, condensati-
on may occur. Please wait until the device has reached the correct temperature and is
absolutely dry before putting it into operation. The acclimatization time depends on
the temperature difference and the device as well as its construction. However, it
should be at least 12 hours.
Please wear protective gloves during installation to avoid the ri
sk of injury. Before
mounting the hood, prepare the necessary tools.
For the installation of the hood, the customer must provide the prerequisites for a
smooth installation of the hood and cover kitchen appliances.
Prepare a suitable exhaust air duct, if necessary open false ceiling, partition walls,
kitchen block, create openings etc...
14
EN
6. ASSEMBLY PREPARATION
Safety instructions
Assembly, connection, commissioning and repair may only be carried out by a specialist.
This specialist can determine the suitable mounting and exhaust air routing of the cooker hood.
Risk of injury!
Sharp edges may be present in the vented hob due to production.
Wear protective gloves during assembly!
Danger of electric shock!
The mains voltage must correspond to the specifications on the nameplate. Only connect the
vented hob to a properly installed socket outlet with earthing contact. The socket must be
easily accessible after installation so that the vented hob can be disconnected from the mains
voltage if necessary. If the appliance is permanently connected (e.g. if there is no socket), the
vented hob may only be connected to the mains voltage by a qualified electrician. For permanent
connection, the vented hob must be connected to a single circuit with a disconnecting device. Switches
with a contact opening of at least 3 mm and all-pole switches, e.g. LS switches and contactors, are
regarded as disconnecting devices. Switch off the mains circuit(s) before working on the electrical
connection of the vented hob. Before drilling fixing holes, check that no electrical cables can be damaged
by drilling. The electrical connection must be prepared so that the vented hob can easily be connected.
Local regulations must be observed.
Exhaust air duct (for exhaust air operation)
The exhaust air must not be led into a chimney which is used for exhaust gases from devices with fuels
(e.g. gas). Official regulations for the discharge of exhaust air must be observed. The exhaust air path
must be prepared in such a way that the vented hob can easily be connected to it. The exhaust hose must
be laid without kinks. If the vented hob is operated simultaneously with other room air dependent
fireplaces (e.g. wood-, gas-, oil- or coal-fired appliances) in one room during exhaust air operation, deadly
combustion gases can be returned to the room through a negative pressure. The operator must therefore
ensure an adequate supply of air at all times. The negative pressure in the room must not exceed 4 Pa
(0.04mbar). Do not exceed max. duct length of 5m with B-version.
Fireplace for solid fuels
The vented hob may only be installed above a fireplace for solid fuels from which there is a risk of fire
(e.g. flying sparks) if the fireplace has a closed, non-removable cover.
Installation
The device may only be connected by authorised specialists in compliance with all relevant regulations of
the power supply companies as well as the building regulations of the federal states. Observe the
corresponding instructions during installation! Damage to the device must be reported immediately upon
delivery. Damaged devices may be installed. Defective parts must be replaced by original parts. Repairs
may only be carried out by authorised specialist personnel.
Air turbulence can occur at high levels with C recirculation air versions!
Before the cooker hood leaves our factory, it is subjected to a detailed functional test by our quality control
department before being shipped.
The pictures, drawings and models shown in the operating instructions may differ from the model supplied
or may contain options which are not included in the scope of delivery.
We reserve the right to make technical changes!
Warnings in these operating instructions are placed in front of an instruction that may
result in personal injury or property damage.
Measures to avert a hazard must be observed.
WARNING
SIGNS
MEANING
Warning of a danger spot !
Indicates potentially dangerous situations. Failure to observe the
warn
ing notices may result in personal injury and/or damage to
property.
Warning of dangerous voltage!
Indicates possible hazards due to electricity. Failure to observe the
warnings may result in death, injury and/or property damage.
Warning of hot surface !
Indicates possible hazards due to high surface temperatures.
Failure to observe the warnings may result in personal injury and/or
damage to property.
Warning of hand injuries !
Indicates possible hazards due to moving and rotating parts. Non-
observance of the warnings can result in personal injury.
Warning of toxic substances !
Indicates possible dangers due to inhalation of toxic gases. Failure to
observe the warnings may result in death or serious poisoning.
Warning of flammable substances !
Indicates possible dangers due to fire hazard. Failure to observe the
warnings may result in death, personal
injury or property damage.
Warning of cuts due to glass breakage !
Indicates possible hazards due to sharp edges. Failure to observe the
warnings may result in cutting injuries and personal injury.
3
EN
WARNING NOTICE AND SYMBOLS
Warnings in these operating instructions are placed in front of an instruction that may
result in personal injury or property damage.
Measures to avert a hazard must be observed.
WARNING
SIGNS
MEANING
Warning of a danger spot !
Indicates potentially dangerous situations. Failure to observe the
warn
ing notices may result in personal injury and/or damage to
property.
Warning of dangerous voltage!
Indicates possible hazards due to electricity. Failure to observe the
warnings may result in death, injury and/or property damage.
Warning of hot surface !
Indicates possible hazards due to high surface temperatures.
Failure to observe the warnings may result in personal injury and/or
damage to property.
Warning of hand injuries !
Indicates possible hazards due to moving and rotating parts. Non-
observance of the warnings can result in personal injury.
Warning of toxic substances !
Indicates possible dangers due to inhalation of toxic gases. Failure to
observe the warnings may result in death or serious poisoning.
Warning of flammable substances !
Indicates possible dangers due to fire hazard. Failure to observe the
warnings may result in death, personal
injury or property damage.
Warning of cuts due to glass breakage !
Indicates possible hazards due to sharp edges. Failure to observe the
warnings may result in cutting injuries and personal injury.
3
EN
WARNING NOTICE AND SYMBOLS
Safety instructions for the kitchen furniture fitter
Veneers, adhesives or plastic coverings of adjacent furniture must be temperature-
resistant (min. 75°C). If the veneers and coverings are not sufficiently temperature-
resistant, they may deform.
The use of solid wood wall end strips on the worktop behind the hob is permitted,
provided that the minimum distances are observed in accordance with the
installation sketches.
The minimum distances of t
he recess cut-outs to the rear according to the
installation sketch must be observed.
For installation directly next to a tall cabinet, a safety distance of at least 50 mm
must be maintained. The side surface of the tall cabinet must be covered with heat-
resistant material. For technical reasons, however, the distance should be at least
300 mm.
The packaging materials (plastic foils, polystyrene, nails, etc.) must be taken out of
the
reach of children, as these parts represent possible sources of danger. Small
parts could be swallowed and foils pose a suffocation hazard.
Ventilation
The induction hob has a fan that automatically switches on and off. If the
temperature values of the electronics exceed a certain threshold, the fan starts at a
low speed. If the induction hob is used intensively, the fan switches to a higher
speed. If the electronics have cooled do
wn sufficiently, the fan reduces its speed
and switches off again automatically.
The distance between the induction hob and kitchen furniture or built-in appliances
must be chosen so that sufficient ventilation of the induction is guaranteed.
To ventilate the hob
electronics, open the rear
wall of the base cabinet in
the area of the hob. The
front crossbar of the base
cabinet must be removed
over the entire width of
the hob.
In addition, an
air gap of at
least 5 mm at the front
below the worktop is
mandatory.
EN
16
3
Flush mounting
Surface mounting
15
EN
7. FITTING REQUIREMENTS
95>
SECTION A-A
584
934
905
65> 540
A A
7
R
7
700>
700>
95>
54065>
905
41
ENPRELIMINARY REMARKS
