Decide where to locate the light strips
and ensure wiring has enough length
for control box to be installed in
desired location.
STEP 1
INSTALLATION
EXTENSION WIRE
FUSE
As shown below, connect all light strips to the control box with the included
extension cables.
1.
2.
Connecting to more than 10 AMP will override the kit and cause early failure,
ensure it is 10AMPs or less!!
Please ensure that the LED bars or strips/control box/wiring all are mounted
in areas where will not exceed 85℃ or 185℉.
WARNING
To Next Page
