Separate box
Separate box tamper
Main unit
Bracket
Fixture
Main unit cover
Lens
1-2
PARTS IDENTIFICATION
Connector for POWER and ALARM
Connector for TROUBLE
Screw kit
For joint For wall mounting
Screw (M3 × 10 mm)
Plate nut
Screw (3 × 20 mm)
Note>>
Transmitter and battery are not included.
-Optional accessories
Wall tamper (WRS-03)
•
Separate box cover
Sponge
Sponge
Sponge for transmitter
- 3 -
