Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
4. System Options4. System Options
4.2 Walk Test Mode4.2 Walk Test Mode
This sections determines which output(s) will activate when a zone (programmed as a
Walk Test zone) is activated during a Walk Test. (See 2.7.7. Walk Test)
4.2.1 Bell 1
BELL OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.2 Bell 2
BELL OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.3 Relay 1
RELAY OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.4 Relay 2
RELAY OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.5 PGM 1
PGM OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.6 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.7 PGM 3
PGM OUTPUT 3
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 3 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.3 System Features4.3 System Features
This section defines has the user may interact with the SMDC with history viewing
operation of the clock, power delays of the SMDC.
4.3.1 History View by User
HIST VIEW USER
YES 0=NO 1=YES
Selections: Yes / No
Default: Yes
Enable this option to allow the users to view all historical events that have occurred.
(see 0 Pager/Fax/Printer / users manual).
NoteNote: The SMDC control/communicator is able to log 512 total events.
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
To Next Page
