Technical data
Version 1.1.4 - 2022-09-2310 Originalbetriebsanleitung
GH 10T | GH 15T
EN
GH10T_GH15T_GB_2.fm
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data.
2.9 Emissions
The generation of noise (emission) emitted by the drill bit grinder is less than 69 dB(A).
If the drill bit grinder is installed in an area where various machines are in operation, the noise
exposure (immission) on the operator of the drill bit grinder at the working place may exceed 80
dB(A).
INFORMATION
This numerical value was measured on a new machine under proper operating conditions.
Depending on the age respectively on the wear of the machine it is possible that the noise
behaviour of the machine changes.
Furthermore, the factor of the noise emission is also depending on manufacturing influencing
factors, e.g. speed, material and clamping conditions.
INFORMATION
The mentioned numerical value is the emission level and not necessarily a safe working level.
Though there is a dependency between the degree of the noise emission and the degree of the
noise disturbance it is not possible to use it reliably to determine if further precaution measures
are required or not.
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
2.1 Electrical connection
GH 10T GH 15T
IEC power connector 230 V ~50Hz 230 V ~50Hz
Motor power 180W 450W
2.2 Speed
Speed superabrasive product 5000 min
-1
Max. grinding speed [ m/s ] 21 29
2.3 Grinding disc
Steel disc, coated with
cubic crystalline boron nitride
13C-CBN#170/200 PP26-CBN#170/200
2.4 Collect chuck seat
Type, similar ER20 ER40
and
ER20
2.5 Point angle
adjustable 90° - 135° 90° - 145°
2.6 Grinding capacity
Grinding capacity of spiral drill Ø 2mm - Ø 13mm Ø 3mm - Ø 30mm
2.7 Dimensions
Height [mm] 150 220
Depth [mm] 140 220
Width [mm] 290 435
Net weight [ kg ] 9.5 35
Gross weight [ kg ] 10 39
Dimension of the packing L x W x H [mm] 310 x 180 x 190 450 x 240 x 270
2.8 Environmental conditions
Temperature 5-35 °C
Humidity 25 - 80%
