6
CONNECTING THE INPUT SOURCE
Using the Autosound System’s Line-Out Jacks
If your autosound system has line-out jacks, use shielded audio cables with left and
right phono connectors to make these connections.
Note:
If your autosound system does not have line-out jacks, see “Using the Auto-
sound System’s Speaker Wires” on Page 7.
1. Connect the phono plugs on one
end of an audio cable to the
equalizer’s
L
(left) and
R
(right)
LINE INPUT
jacks.
2. Connect the phono plugs on the
other end of the audio cable to
your autosound system’s left and
right line-out jacks.
3. Connect the output amplifiers
using the following guidelines:
• If you are using your autosound
system as the amplifier, see
“Using Your Autosound Sys-
tem’s Amplifier” on Page 8.
• If you are using separate ampli-
fiers, see “Using Separate
Amplifiers” on Page 9.
(illus – Show only the auto-
sound system’s line-out
jacks connected to the equal-
12-1978.fm Page 6 Tuesday, July 13, 1999 10:31 AM
