CONNECTING OUTPUT AMPLIFIERS
Using Your Autosound System’s Amplifier
If your autosound system also has line-in jacks so you can use it as the speaker
amplifier, use shielded audio cables with left and right phono connectors to make
this connection.
Note
: To get a higher output power than what your autosound system can produce,
you can connect front, rear, and one or two subwoofers, see “Using Separate Am-
plifiers” on Page 9.
1. Make sure your autosound sys-
tem’s speaker harness is con-
nected to the speakers.
2. Connect the equalizer’s
FRONT
(or
REAR
)
L
(left) and
R
(right)
line-out jacks to your autosound
system’s left and right line-in
jacks.
3. Proceed to “Connecting Power”
on Page 10.
(illus – show the autosound sys-
tem’s line-out jacks connected to
the equalizer’s
LINE INPUT
jacks
and
the equalizer’s
FRONT
and
REAR
jacks connected to the autosound
