M130 Version 1.0 Page 15 of 23
M130
8x8 Audio Matrix
5. TECHNICAL SPECIFICATIONS OF M132M
Electrical Specifications:
Microphone inputs
Gooseneck microphone input -50 dB Balanced
Audio Output
Line Output 0 dB Balanced
RS-422 Interface
Communication Speed 19.200 bps
Full Duplex, Multi-Drop methods, Data 8 bits, Stop 1 bit, Start 1 bit, non parity.
Maximum communication distance: 1.000 m, using CAT5 STP.
Signal to Noise Ratio (SNR)
> 90 dB
THD
< 0,01 % at 100 Hz ~ 10 kHz
Phantom Power
24 VDC
0 dB = 1Vrms
General Specifications:
Power Source
24 VDC
Power Consumption
< 10 W
Weight
1,5 kg
Dimensions
175 (W) x 69 (H) x 210 (D) mm
Temperature / Humidity
0 ~ 40ºC / < 95 %
Specifications can be changed without notice.
