Alternate Outlet Locations
The OptiPure Manifold System has the ability to be flexible with treated water outlet locations. The
outlet fitting can be switched to the other end of the Manifold System if Inlet and Outlet needs to be
on opposite sides of the system.
Multi-Function Valve Wrench
The OptiPure Manifold Systems include a wrench to help turn the Multi-Function Valve positions.
Insert wrench as shown to help rotate handles 90 degrees in each direction from Service Position.
REMOVE CLIP
AND FITTING
BOTTOM OUTLETS
FOR FULL FLOW
TOP OUTLET FOR
RESTRICTED
TREATED WATER
FLOW
INLET IS ALWAYS
TOP LEFT PORT
OPENING!
BOTTOM OUTLETS
FOR FULL FLOW
ALTERNATE
OUTLET
