Optoma EW330 - Table of Contents

IV
Condential
EX330/EW330/EX330(1W)/EW330(1W)
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lens Cap Module and Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Keypad Board and Keypad 2-4
Disassemble Focus Ring 2-4
Disassemble Front Cover 2-5
Disassemble IR Sensor Board and IR Sensor Cover 2-5
Disassemble Disassemble Main Board Module 2-6
Disassemble Separate Main Board and Rear Cover 2-6
Disassemble Thermal Switch 2-7
Disassemble Ballast Module 2-7
Disassemble DC-DC Module 2-8
Disassemble Fan Module 2-9
Disassemble Blower Module 2-10
Disassemble Color Wheel Module 2-11
Disassemble Engine Module 2-11
Disassemble Heat Sink,DMD Board and DMD Chip 2-12
Disassemble Rod Module 2-12
Disassemble Interlock Switch 2-13
Rod Adjustment 2-14
Re-write Lamp Useage Hours 2-16
