Optoma EX550 - Board;Module; Case;Cover;Bracket Assembly; Optical Device; Fans

44
6.2 Board/Module
Key No. P/N Description
PA784-7100
ES550_MAIN_DIP_PCB
PA884-7100
EX550_MAIN_DIP_PCB
PC384-7100
ES551_MAIN_DIP_PCB
B01
PC484-7100
EX551_MAIN_DIP_PCB
B02
PA884-8100
POWER_ASY
B03
PA884-9000
BALLAST_ASY
B04
PA884-7500
FIR_DIP_PCB_ASY
6.3 Case/Cover/Bracket Assembly
Key No. P/N Description
C01
PA884-4540
LAMP-COVER_ASY
C02
PA884-4500
TOP-COVER_ASY
C03
PA134-4540-99 KEY_ASY
C04
PA884-4510
BOTTOM-COVER_ASY
6.4 Optical Device
Key No. P/N Description
PA784-2200
OPTICAL ENGINE SIMPLE_ ES550
PA884-2200
OPTICAL ENGINE SIMPLE_ EX550
PC384-2200
OPTICAL ENGINE SIMPLE_ ES551
O01
PC484-2200
OPTICAL ENGINE SIMPLE_ EX551
PA884-2400
LAMP MODULE_ES550_EX550
O02
PC484-2400
LAMP MODULE_ES551_EX551
6.5 Fans
Key No. P/N Description
F01
02394-0151-00 FAN.1
F02
02394-0150-00 FAN 2
F03
02394-0152-00
FAN 3
6.6 Speaker
Key No. P/N Description
SP01
02413-0117-00
SPEAKER
