Optoma HD65 - Adjusting the Projected Image

15
English
Installation
Adjusting the Projected Image
Adjusting the Projector’s Height
The projector is equipped with elevator foot for
adjusting the image height.
To raise the image:
1. Press the elevator button .
2. Raise the image to the desired height angle , then release
the button to lock the elevator foot into position.
3. Use screw in foot  to ne-tune the display angle.
To lower the image:
1. Press the elevator button.
2. Lower the image, then release the button to lock the
elevator feet into position.
3. Use screw in foot  to ne-tune the display angle.
Tilt-Adjustment Foot
Elevator Foot
3
2
Elevator Button
1
