Add a Storage Expansion Shelf Into an Existing System
Chapter4 • Installing the System Into a Rack 95
Staff, Tools, and Equipment Required to Rackmount the
System
Caution - Personal injury or equipment damage. Use a mechanical lift to install
the system or follow the precautions in “Removing Components to Reduce System
Weight” on page 95.
Before starting the installation, gather the staff, tools, and equipment required to rackmount the
system.
Staff, Tools, and Equipment Notes
Four trained staff Four people are needed to lift or transport the system.
Note - If a mechanical lift is available or components
have been removed from the system, it is safe for two
people to lift or transport the system.
No. 2 10-inch Phillips screwdriver A magnetic tip is recommended.
Mechanical lift Strongly recommended. If not available, reduce the
weight of the system. See “Removing Components to
Reduce System Weight” on page 95.
Compatible four-post rack See “Rack Compatibility Requirements” on page 60.
Rackmount kit See “Rackmount Kit Contents” on page 93.
Transportation kit See “Transportation Kit Contents” on page 108.
Antistatic wrist strap and antistatic mat Required only if you remove system components.
Removing Components to Reduce System Weight
Before installing Oracle Database Appliance Version 1 into a rack, you can remove components
to reduce the weight of the system so that two persons can lift the system into the rack.
Removing system components reduces the weight to approximately 96 pounds (43.5 kg).
Remove the following components to reduce the system weight:
■
Server nodes
■
Power supplies
Note - Because of their light weight, you do not need to remove filler panels from the system.
For instructions on removing components from the system and associated safety information,
see the Oracle Database Appliance Service Manual.
