Oracle Talari E100 User Manual

12
Oracle Talari E100 Hardware Guide
Hardware Specifications
The E100 APNA has the following are the hardware specifications.
Power
100-240V, 50-60 Hz, 3-1.5 Amp Max, 200W
Physical Dimensions
EIA RS-310 standards 1U
Height 1.7” (44mm)
Width 16.9” (431mm)
Depth 12.0” (305mm)
Gross Weight 11lbs (5kg)
Mounting Options
Rack mount recessed flanges
System LEDs Front Panel
Power
Status
HDD
Link LEDS Front Panel
Link Activity
Link Speed
Operating Temperature
32°F to 104°F (0° to 40°C)
Storage Temperature
-4°F to 158°F (-20°C to 70°C)
Humidity Range
5% to 90% (non-condensing) operating environment
5% to 95% (non-condensing) storage environment
Capacity
6 individual Gigabit Ethernet Ports
User interfaces
2 front accessible USB 2.0 ports
Console Port
6 individual Gigabit Ethernet ports
Mean Time Between Failure
(MTBF) in Hours
47,934
Specification

Oracle Talari E100 Specifications

General

Brand	Oracle
Model	Talari E100
Category	Network Hardware
Language	English
