Oracle Talari E100 Hardware Guide
Network Deployment Options
Before getting started it is important to determine how the E50 will be deployed. When
considering deployment options for the E50, please note that all bypass pairs will
default to Fail-To-Block until configured otherwise.
Example instructions for some of the most common deployment scenarios are provided
below:
E50 as a Router (Gateway, Fail to Block)
Description: The E50 is deployed as the WAN gateway for the site, and bypass pairs
are configured as Fail-To-Block. Use this design if you plan to use the Talari
Appliance as the edge device for the site. Proceed to the following sections based on
your installation method:
Easy 1
st
Install
Manual Install
E50 as Layer 2 Fail-To-Wire (Overlay)
Description: The E50 is deployed on the LAN side of the gateway, and bypass pairs
are configured as Fail-To-Wire. Use this design if you prefer to retain existing edge
devices or plan to install an alternative edge device on the WAN side of the Talari
Appliance. Proceed to the following sections based on your installation method:
Easy 1
st
Install
Manual Install
E50 with MPLS & Internet Hybrid
Description: The E50 is deployed as an overlay for MPLS while performing
routing/firewall capabilities for internet links. Use this design if recommended by your
SA, or if you have an MPLS/Internet hybrid network and will not be using the CE Router
Replacement functionality of the Talari APN. Proceed to the following sectionsbased on
your installation method:
Easy 1
st
Install
Manual Install
Other Options
There are other deployment options, and our Talari Implementation team members
will assist you with planning and deploying your new appliance.
