Orange Pi PC - 40-Pin GPIO Pin Mapping

Orange Pi PC User Manual Shenzhen Xunlong Software CO., Limited
www.orangepi.org www.xunlong.tv
CON3-P04 VCC-5V
CON3-P05 TWI0-SCK PA11
CON3-P06 GND
CON3-P07 PWM1 PA6
CON3-P08 UART3_TX PA13
CON3-P09 GND
CON3-P10 UART3_RX PA14
CON3-P11 UART2_RX PA1
CON3-P12 PD14 PD14
CON3-P13 UART2_TX PA2
CON3-P14 GND
CON3-P15 UART2_CTS PA3
CON3-P16 PC4 PC4
CON3-P17 VCC-3V3
CON3-P18 CAN_RX PC7
CON3-P19 SPI0_MOSI PC0
CON3-P20 GND
CON3-P21 SPI0_MISO PC1
CON3-P22 UART2_RTS PA2
CON3-P23 SPI0_CLK PC2
CON3-P24 SPI0_CS0 PC3
CON3-P25 GND
CON3-P26 PA21 PA21
CON3-P27 TWI1-SDA PA19
CON3-P28 TWI1-SCK PA18
CON3-P29 PA7 PA7
CON3-P30 GND
CON3-P31 PA8 PA8
CON3-P32 UART1_RTS PG8
CON3-P33 PA9 PA9
CON3-P34 GND
CON3-P35 PA10 PA10
CON3-P36 UART1_CTS PG9
CON3-P37 PA20 PA20
CON3-P38 UART1_TX PG6
CON3-P39 GND
CON3-P40 UART1_RX PG7
Specification of CSI Camera Connector
CSI Camera Connector
The CSI Camera Connector is a 24-pin FPC connector which can connect external camera module
with proper signal pin mappings. The pin of CIS connector can be defined as follows. The connector
marked with “CON 1” on the Orange Pi PC is camera connector.
