ORANGE 100BXT - Rear Panel

11
REAR PANEL
NAME
DESCRIPTION
20
AC MAIN POWER
SWITCH
This switch turns the AC Main Power on/off
21
AC INLET &
FUSEHOLDER
Connect the supplied standard 3-pin ‘IEC’ plug here
WARNING: This amplifier shall be connected to a mains socket outlet with a protective earthed connection.
WARNING: Where the mains plug or appliance inlet is used as the disconnect device, the disconnect device shall remain readily operable.
