Page #5 background imageLoading...
Page #5 background image
5
OR15
ENGLISH
IMPORTANT SAFETY INFORMATION
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated ‘dangerous voltage
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons. Terminals labelled as “Speaker Outputs” must
be connected to a speaker cabinet of the designated load rating using an un-
shielded two conductor cable for speaker use at all times during operation
The exclamation point within an equilateral triangle and "WARNING" are
intended to alert the user to the presence of important operating instructions.
Failure to heed the instructions will result in severe injury or death.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near liquid.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ORANGE OR15 and is the answer not in the manual?

ORANGE OR15 Specifications

General IconGeneral
Power Output15 Watts
Channels1
FootswitchNo
ControlsGain, Volume
ValvesECC83, EL84
TypeTube Amplifier
Impedance16 Ohm, 8 Ohm
Speaker1 x 10" Voice of the World
Effects LoopYes
Speaker Output1 x 16 Ohm
Dimensions48 x 24 x 24 cm
