ORANGE OR15 User Manual

7
OR15
ENGLISH
Connect the supplied mains cord to the AC Mains Input on the amplifier to your
AC mains wall outlet. This Class I electrical equipment must be earthed. The
correct mains fuse value for your region are displayed on the unit, close to the
AC Mains Input. Replace only with the same type and value. If the mains fuse
repeatedly blows, contact your Orange dealer.
EMI
To reduce the possibility of outside electrical interference during performance, operate your amplifier
and instrument away from appliances/equipment that generate high levels of
electronic/electromagnetic noise. This may include, but is not limited to: fluorescent lighting,
refrigerators, motors, mobile phones, radios, computers etc.

ORANGE OR15 Specifications

General

Power Output	15 Watts
Channels	1
Footswitch	No
Controls	Gain, Volume
Valves	ECC83, EL84
Type	Tube Amplifier
Impedance	16 Ohm, 8 Ohm
Speaker	1 x 10" Voice of the World
Effects Loop	Yes
Speaker Output	1 x 16 Ohm
Dimensions	48 x 24 x 24 cm
