ORANGE OR50 User Manual

1
OR50
OWNERS MANUAL
REAR PANEL FEATURES
SPEAKER OUTPUTS (8 Ω, 8 Ω, 16 Ω)
Please refer to “Using Your Amplifier”.
HT FUSES (HT1, HT2)
2 x T500mA
These fuses will both blow simultaneously if either of the power amp/output stage valves
fail. This helps to protect the amp’s circuitry. Have a qualified service technician set the
bias of the amplifier when changing faulty valves.

ORANGE OR50 Specifications

General

Power Output	50 Watts
Inputs	1 x 1/4" Instrument Input
Type	Valve/Tube Amplifier
Controls	Volume, Bass, Middle, Treble
Tubes	3 x ECC83
Impedance	8 Ohms
Outputs	Speaker Outputs: 1 x 16 Ohm, 2 x 8 Ohm
Dimensions	55 x 27 x 28 cm
