FRONT PANEL FEATURES
Input Jack Socket
Plug your instrument into this jack socket.
Power toggle switch
This turns on the mains power to the amplifier.
STBY toggle switch
When this switch is in the up position, the amp is in STBY mode. Refer to ‘Before Using
Your Amplfier’. Select the PLAY (down) position for performance.
Volume Control Defeat Jack socket
Plug a latching footswitch into this jack socket to remotely switch/remove the Volume
Control from the circuit. This has the effect of running the amp ‘wide open’. This can be
used as a volume boost as the volume control is bypassed.
