Using Your Amplifier
IMPORTANT! Before connecting your amplifier to a power source, please check the following:
1. Ensure your speaker cabinet is connected to the correct impedance speaker output socket, (see Rear Panel, item 2), using a
good quality speaker cable. Do not use guitar leads.
2. Ensure that the voltage selector switch is set to the correct mains voltage, (see Rear Panel, item 5).
When powering up your amplifier, switch to the ensure the ‘Standby’ position is set from the front panel and then switch the power on from the rear
panel, two minutes before switching from 'Standby' to the ‘On’ position. (This will maximise the life of your valves)..
If you are unsure about any of the above points please consult your local Orange supplier.
When powering on the amplifier make sure that the ON/STBY/OFF output switch is in the Standby (middle) position for at least one minute before
switching the power switch to the ON position. (This will maximise the life of your valves).
If you are unsure about any of the above points please consult your local Orange supplier.
Using The Rockerverb 50/100
Using The Dirty Channel
This channel features five controls, Volume, Treble, Middle, Bass and Gain.
Using Clean Channel
This channel features four controls, Treble, Middle, Bass and Volume.
Using the Footswitch
Connect your Orange footswitch to either the Channel switch jack or the Reverb jack, (see Rear Panel, item ).
Technical Specifications
Rockerverb 50 Head MKII Rockerverb 50 1 x 12 Com bo MKII Rockerverb 50 2 x 12 Combo MKII Rockerverb 100 Head
Power
50 w atts 50 w atts 50 w atts 100 w atts
Channel Configuration
Clean / Dirty Clean / Dirty Clean / Dirty Clean / Dirty
Speaker
- 1 X 12" Celestion Vintage 30 2 X 12" Celestion Vintage 30 -
Reverb
Valve Driven Valve Driven Valve Driven Valve Driven
Footsw itch Function
Channel / Reverb Channel / Reverb C
hannel / Reverb Channel / Reverb
Inte rchangeble Pow er Valves**
YesYesYesYes
Pream p Valves
4 X ECC83 / 12AX7 4 X ECC83 / 12AX7 4 X ECC83 / 12AX7 4 X ECC83 / 12AX7
Power Valves
2 X EL34 2 X EL34 2 X EL34
4 X EL34 / 6L6GC
Reverb Valves
3 X ECC81 / 12AT7 3 X ECC81 / 12AT7 3 X ECC81 / 12AT7 3 X ECC81 / 12AT7
Clean Channel Controls
Volume / Bass / Treble Volume / Bass / Treble Volume / Bass / Treble Volume / Bass / Treble
Dirty Channel Controls
Gain / Volume
Bass / Middle / Treble
Gain / Volume
Bass / Middle / Treble
Gain / Volume
Bass / Middle / Treble
Gain / Volume
Bass / Middle / Treble
Other Controls
Reverb Reverb Reverb Reverb
Weight
23.5kg / 52lb 31kg / 70lb 38kg / 84lb 27kg / 60lb
Dim ensions (m m )
550 X 280 X 255 500 X 300 X 533 660 X 300 X 533 550 X 280 X 255
