IMPORTANT NOTE: Refer to the unit’s rear panel for your Model #.
Model Number: Description:
8200/U3S OPTIMOD-FM 8200 DIGITAL with three DSP cards, Stereo Encoder,
Protection Structure, Two-band Purist Structure, Two-band Normal
Structure, Multi-band Processing Structure, set to 115V (for 90-130V
operation), switchable to 50µs or 75µs.
8200/E3S OPTIMOD-FM 8200 DIGITAL with three DSP cards, Stereo Encoder,
Protection Structure, Two-band Purist Structure, Two-band Normal
Structure, Multi-band Processing Structure, set to 230V, (for 180-260V
operation), switchable to 50µs or 75µs.
OPTIONS AVAILABLE:
Model Number: Description:
CIT25 Composite Isolation Transformer.
8200D/32 Digital I/O Card, 32kHz
8200 PC Remote Control Software for IBM PC compatible computers
MANUAL:
Part Number: Description:
95100-301-01 8200 Manual (includes 8200 PC Manual)
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This symbol, wherever it appears, This symbol, wherever it appears,
alerts you to the presence of uninsulated alerts you to important operating and
dangerous voltage inside the enclosure — voltage maintenance instructions in the accompanying
that may be sufficient to constitute a risk of shock. literature. Read the manual.
