GAIN TECHNICAL SPECIFICATIONS
13
*
The X35 battery has 2 cables in one end (that
will stay in the top part of the frame) and 3 in the
opposed end.
CHARGING PORT
DERAILLEUR
DISC
BRAKE
MOTOR
PASS
SENSOR
CABLE ROUTING
X35 BATTERY
