INSTRUCTIONS
GUIDE PLACEMENTE IN THE BATTERY
*
First, attach the guides in both ends of the battery
with the double sided Scotch tape before attaching
it to the frame.
iWOOK ONE + TRIO + SCREEN
CHARGIN PORT
BATTERY X35
DOUBLE SIDED
TAPE
LIGHT
MOTOR
SENSOR
INSTRUCTIONS
BATTERY PLACEMENT IN THE FRAME
*
Once the guides are attached in the battery, insert
it into the frame with 2 cables in one end and 3 in
the other (as shown in picture above) until matching
the 3 frame holes with the 3 in the battery.
