GAIN TECHNICAL SPECIFICATIONS
16
CABLE ROUTING
IWOC ONE CABLE ROUTING
*
The cable routing for the start button IWOK ONE
will be done through the steering tube.
iWOOK
ONE
LIGHT CABLE
(OPTIONAL)
Ø
20 HOLE
STEERING TUBE
