Orbit JETRONIC-BOX – Manual 1.2
3/4/5:RC3/4/5-CONTROL – Settings for the Outputs RC3, RC4 and RC5
30:RC3-MODE
Specifies the basic function for the remote control output RC3.
OFF: The output is switched off and disabled.
RC1-DIRECT for gears and doors that remain open (bistable function)
The remote control signal OFF/ON at the RC1 input switches the output
between the positions 34:RC3-LOW and 36:RC3-HIGH.
RC1-TRIGGER for doors that close again automatically (monostable function)
An OFF
→
ON change of the remote control signal at the RC1 input switches the
output to the position 36:RC3-HIGH for the times specified with 31:RC3-WAIT-ON
(RC1=ON).
An ON
→
OFF change of the remote control signal at the RC1 input switches the
output to the position 36:RC3-HIGH for the times specified with 32:RC3-WAIT-
OFF (RC1=OFF).
After this time, the output returns to the position 34:RC3-LOW.
RC1-DIR.&POS. works like RC1-DIRECT, but is logical AND'ed with the retracts position-switch.
To this 20:RC2-MODE must be set to POS.-SWITCH.
RC1-TRIG.&POS. works like RC1-TRIGGER, but is logical AND'ed with the retracts position-
switch. To this 20:RC2-MODE must be set to POS.-SWITCH.
RC1-PROP: The output follows the remote control signal at the RC1 input proportional.
Default setting: OFF
31:RC3-WAIT~ON
Specifies the ON delay.
Range: 0 – 20 seconds
Default setting: 0.0 sec
32:RC3-WAIT~OFF
Specifies the OFF delay.
Range: 0 – 20 seconds
Default setting: 0.0 sec
33:RC3-DIRECTION
Specifies the direction of rotation: NORMAL or REVERSE.
Default setting: NORMAL
34:RC3-LOW
Specifies the lower end position (LOW).
Range: +-150 %
Default setting: -100 %
14
