Orbit OBK 794 User Manual

PARTS LIST
Part
No.
Description Qty
Part
No.
Description Qty
1 Main frame 1 39 Circle 2
2 Front stabilizer 1 40 Crank cover 2
3 Rear stabilizer 1 41L/R Chain cover 1each
4 Front vertical tube 1 42 Screw ST4.2×18 10
5 Handle bar 1 43 Spring washer D17 2
6 Saddle supporting tube 1 44 Screw ST3×10 2
7 Saddle 1 45 Crank sealing 2
8 Resistance wire 1 46 Nylon nut M6 3
9 Computer 1 47 Bearing 6003 2
10L/R Pedal 1each 48 Belt tray 1
11 End cap 2 49 Axle 1
12 Leveling feet 2 50 Belt 1
13 Square neck bolt M8×73 4 51 Flywheel 1
14 Arc washer Φ20×d8.5×R30 8 52 Flywheel axle 1
15 Acorn nut M8 4 53 Flange nut M10×1 1
16 Sensor wire 1 54 Idle wheel 1
17 Square end cap 2 55 Flange nut M10×1.25 2
18 Bolt M8×15 4 56 Idler tube 1
19 Flat washer D10 1 57 Spring 1
20 Knob nut M10 1 58 Hex nut M6 4
21 Extended wire 1 59 Hex bolt M6×55 1
22 Flat washer D8 1 60 Bolt M6×15 5
23 Fix pipe 1 61 Flat washer D6 2
24 Handle cover 1 62 Spring washer D6 2
25 Round end cap 2 63 Spring washer D12 2
26 Foam grip 2 64 Magnetic board axle 1
27 Pulse sensor wire 2 65 Magnetic board 1
28 Spring Knob 1 66 Magnetic 8
29 Bushing 1 67 Spring 1
30 T-shaped bolt M8 1 68 Belt wheel 1
31 Horizontal seal post 1 69 Bolt M6×50 2
32 U-Shaped slider 1 70 Hex thin nut M10×1 2
33 Flat washer D5 2 71 Spacer 1
34 Screw M4X12 2 72 Bearing 6000 2
35L/R Crank 1each 73 Washer 2
36 Resistance controller 1 74 Nylon nut M8 2
37 Flat washer 1 75 Spring washer D8 1
38 Screw 1
