Orbit Silver XT - Foot Link End Cap Installation (Step 16)

15
ASSEMBLY INSTRUCTIONS
STEP 16: Install the End Cap on the Right Foot Link using 3 screws 'I', as shown below.
Repeat this procedure for the Left Foot Link.
Right Foot Link
End Cap
Power Cord
Plugs In Here
16
