5
III.ASSEMBLY
STEP 1
1. Lift treadmill out of box by two people and place it lightly on a flat surface, take protective polythene
foams off and put back inside box. Keep fittings nearby.
2. Lift up upright posts as shown in diagram and lock them with 2pcs of M10 knob screws on both sides.
Main
Part
Q'ty
1.Main frame
1set
No.
Fittings
Q’ty
No.
Fittings
Q’ty
M8 Knob
2
5mm Wrench
1
M10 Knob
2
6mm Wrench
1
Silicone oil
1
Multi Wrench
1
Safety Key
1
9
User Manual
1
M6*10
2
NOTICE:ASSEMBLY REQUIRES TWO PERSONS
