Orbit T966 - Parts List

17
PARTS LIST
No Description Specification Qty No Description Specification Qty
1 MAIN FRAME
Left /righ
t side
tube60*30*2.0
1
35
RIGHT BACK COVER
1
2 BASE FRAME
Left/righ
t
connect
tube80*40*2.0
1
36
REAR ADJUSTING KNOB
2
3 LEFT UPRIGHT 100*40*2.0 1
37
RIGHT BOTTLE FRAME
1
4 RIGHT UPRIGHT 100*40*2.0 1
38
TUB PLUG
2
5 COMPUTER BRACKET 1
39
TUB PLUG
2
6
INCLINE SUPPORT FRAME
1 40
FOAM
2
7
REAR INCLINE FRAME
1 41
SIDE RAIL
2
8
SLIDING BLOCK
2 42
NON-SLIP PAD
4
9
MOTOR BRACKET
1 43
MOTOR BOTTOM COVER
1
10
HANDLE BAR BRACKET
Φ31.8*2.0
1 44
SLIDING BLOCK
2
11
LEFT HANDLE BAR
70*41.6*2.0
1 45
MOTOR BELT
1
12
RIGHT HANDLE BAR
70*41.6*2.0
1 46
FOOT PAD
2
13
Z-SHAPE SENSOR CONNECT
1 47
RING PROTECTING WIRE
PLUG
2
14
FRONT ROLLING
1 48
WHEEL PROTECT COVER
2
15
REAR ROLLING
1 49
TRANSPORT WHEELS
4
16
SLIDE RAIL ROD
2 50
ADJUSTING ROLLER
2
17
REAR INCLINE BUSHING
2 51
CUSHION PAD1 RED
2
18
SPRING
1 52
CUSHION PAD2 BLUE
2
19
BOLT
2 53
CUSHION PAD3 BLACK
2
20
5#ALLEN WRENCH
5mm 1 54
TAPER CUSHION PAD
2
21
6#ALLEN WRENCH
6mm 1 55
INNER TUBE PLUG
4
22
PHILIP SCREW DRIVER
S=13、14、15
1 56
INNER TUBE PLUG
2
23
WHEELS BUSHING
4 57
RUNNING BELT
1
24
CYLINDER
2 58
60*30 INNER TUBE PLUG
2
25
BOLT
2 59
MOTOR TOP COVER
1
26
COMPUTER TOP COVER
1 60
PLASTIC PAD
2
27
COMPUTER BOTTOM COVER
1 61
LEFT BOTTLE FRAME
1
28
COMPUTER PANEL
1 62
BOLT
M8*20 4
29
TOP COVER FOR ADJUSTING
SPEED BUTTON
1 63
BOLT
M8*25 4
30
BOTTOM COVER FOR
ADJUSTING SPEED BUTTON
1 64
BOLT M8*40L 20
4
31
SIDE COVER FOR ADJUSTING
SPEED BUTTON
2 65
BOLT M8*50L15
4
32
LEFT WATER BOTTLE
BRACKET
1 66
BOLT M8*60L15
1
33
RIGHT WATER BOTTLE
BRACKET
1 67
BOLT M10*20
12
34
LEFT BACK COVER
1 68
BOLT M10*30L15
2
