Operation Manual
CompactDual – Two in One
© 08/2019 Rev 0 / Subject to change without notice! Page 15/53
Press button
Number (model) of the weld head/welding device
Press button
In this menu item you can specify the number of sectors. The pipe can be divided into up to 6
different segments.
These are calculated automatically, according to the pipe outside diameter, the wall
thickness, the input continuous or step mode (step mode - to be explained later)
Changing the degrees at which the various sectors are active will also be described in
greater detail.
Desired number of sectors
