Main Switch (ON/OFF)
Gas connection ¼“
Connection orbital rotating
motion (Rotation Weld Head,
Wire, AVC, OSC)
Primary Connection
(110-230 VAC)
Remote Control-Foot Switch Power
Supply, Connection Robot,
Connection Update Software
Power Supply
RS 232 (Bluetooth printer,
Update box Orbital Software)
Orbital Remote Control
(wired)
