OREC SF600 - Page 9

OREC SF600/600D
9
CAUTION
Always disconnect the spark plug when the machine is stored or if you want to perform
maintenance.
RECOIL POSITION AND E/G STARTING MOTION
The recoil is located in the left side of the handle(Figure 10)
To start the machine, pull the recoil according to Figure 10 shown.
ADJUSTING THE HANDLEBAR
The handlebar is adjustable in free position to allow all operators to
use the machine.
To adjust the handlebar :
• Unscrew the knob at the low side of the handlebar.
• Pull of the axle with Jack bolt(A, Figure 11).
• Adjust the handlebar as required
• Put the axle, and screw the knob.
Figure 10
Figure 11
A
A
