Oreck LW100 Service Manual | 15
17. Next, remove the toothed lock washer nocing its orientaon. The top of the washer faces out and
meets the bolt. Be certain to orient the toothed washer correctly when you reassemble.
18. Li the fan assembly o the motor sha. Once detached, be careful to keep the felt seal and the
small at washer in place during reassembly.
Toothed Lock
Washer
Toothed Lock
Washer - Top
Toothed Lock
Washer - Boom
Small Flat Washer
Felt Seal (motor-to-
fan housing)
