7
12. Slinky hose: Easy to use
exiblehose.
13.Hoseinlet: Hose connec-
tion location.
14. Extension wand:
Extendsanadditional
ten inches with the push
of a button.
15. MicroFilter:Keepsdirt
and dust from entering
the vacuum motor.
16. Innerbagdoor: Allows
access to the inner bag.
17. BagGasket: Creates a tight
seal to guard against air
leaks. Do not remove.
18. Disposableinnerbag:
Collects debris from the
vacuuming process.
19.HEPAFilter: Helps keep
dust and dirt inside the
vacuum as you clean.
20.HEPAFilterdoor: The HEPA
filter is secured to this door.
21. Micro Filter Frame: Holds
the Micro Filter.
14
17
18
1521
19
Hose inlet side HEPA filter side
10”extension
2016
