Page #12 background imageLoading...
Page #12 background image
12
42 Brushroll, Silver ION 75202-03 1 1
U3720HG / U3720HR: Brushroll 75104-02 1 1
4
2b Pulley, Metal (For Brushroll) 75706-01 1 1
43 Seal, Baseplate 75008-01 1 1
44 Plastic Detent, (uses 2 #49 screws) 75299-01 1 1
45 Complete Baseplate Assembly
includes: #43, 09-75715-56 1 1
#46, #47, #50, #51, #52, #85, #86, #87 Antimicrobial
46 MICRO SWEEP Blade 75700-02 1 1
47 Channel 75701-01 1 1
50 Edge Brush Silver ION 75766-01 2 1
U3720HG / U3720HR: Edge Brush 75766-02 2 1
51 Wheel Axle 03-00630-01M 2/4* 100
52 Soft Rear Wheel, Black 75187-02-0327 2 1
54 Switch, 2 Position Assembly, Lighted 75523-03 1 1
U3720HG / U3720HR:Single Speed Switch 75559-01 1 1
55 U3760HH: Grip Set, Blue Antimicrobial 09-75576-37 1 1
U3720HG: Grip Set Gray Antimicrobial 09-75562-62 1 1
U3720HR: Grip Set Red Antimicrobial 09-75562-63 1 1
56 U3760HH: Cord Wrap Assembly, Black 09-75185-15 1 1
U3720HG:Cord Wrap Assembly, Gray 09-75185-21 1 1
U3720HR: Cord Wrap Assembly, Red 09-75185-18 1 1
57 Handle Tube, Chrome 75190-03 1 1
58 Cord, Harness Assembly, White 75600-02-328 1 1
59 U3760HH: Cord Set, White w/ #81 75556-02-328 1 1
U3720HG / U3720HR:Cord, Harness Assembly, White 75556-03-328 1 1
60 Motor Spring 75283-01 2 1
61 Tube Label 75087-05 1 1
67 Bag Dock Hinge, Black Antimicrobial 75582-02-0327 1 1
User
s Manual
75416-05
11
Magnet Clean V
acuum Protector
MC4BK
1
1
79 Stiffener, Through Bolt Connector (uses different length screws) 75619-01 1 1
81 Cord Flex Relief 03-00600-01 11
83 Kit, Bag Dock, includes items #4 & #67 Antimicrobial 09-75657-02 1 1
87
Front Wheel
75709-01 2 1
92 Odorfighter Patch 3 pack (not shown) ODOR3PK 3 1
Odorfighter Patch 25 pack (not shown) ODOR25PK 25 1
*Type 7 Units
Part Numbers Listing: U3760HH / U3720HG / U3720HR
Hypo Bag, Lights, Helping Hand Handle, Antimicrobial Units
# Item Order # Qty. Pk.
