24
Saw Chain
2. To set the proper
grinder head angle,
use the recommended
ttoopp--ppllaattee ccuuttttiinngg aannggllee
(
See pages 35-63
for correct angles
for each Oregon
®
chain type.)
3. Dress vitrified grinding wheels often to maintain
correct shape (see illustration). Use either a rotary
wheel dresser or a dressing brick.
Full Radius, for all
FFoorr 1111HH CChhaaiinn OOnnllyy::
round-ground chains 3/16" Partial Radius
except 11H & 1/8” Flat
NOTE:
• To avoid burning cutters, use light intermittent strokes.
• Never grind into other chain components.
• If damage is present on the chrome surface of top
plates or side plates, grind back until such damage is
removed.
• Keep all cutter lengths equal.
25436_Txt_2005.qxd 9/20/2004 12:15 PM Page 24
