6. RS-232 Command
The product also supports RS-232 command control. Connect the RS-232 port
of the product to a PC with a 3-pin phoenix connector cable. Then, open a
Serial Command tool on PC to send ASCII commands to control the product.
The ASCII command list about the product is shown as below.
ASCII Commands
Serial port protocol. Baud rate: 57600 (default); Data bits: 8bit; Stop bits:1; Check bit: 0
x - Parameter 1; y - Parameter 2; ! - Delimiter
Command Code
Function Description
System Information Command
RESET
Reset System To Default Setting
(Should Type "Yes" To Confirm, "No" To Discard)
OUT DSM xx
Set Video Output mode
xx=[00...01] 00:FORCE 01:AUTO
EDID CP yy
Set Input:xx EDID Copy From Output:yy
yy=[01...02]: Select One OUTPUT Port
? Print Help Information
HELP Print Help Information
STATUS Print System Status And Port Status
System Control Command
Video Output Control Command
Input And Output Port Control Command
EDID DF zz
Set Input:xx EDID To Default EDID:zz
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=06: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM
zz=07: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
zz=08: HDMI 4K@60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
zz=09: HDMI 4K@60Hz 4:4:4, Audio 2CH PCM
zz=10: HDMI 4K@60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=11: HDMI 4K@60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
