Orei UHD-404 - Product Specifications; Technical Specifications; Connections and Ports

Specication
Technical
HDCP Compliant HDCP 2.2 / 1.x
Video Bandwidth 594MHz / 18Gbps
Video Resolution 480i ~ 1080p 50/60Hz, 4Kx2K@24/30Hz,
4K2K@60Hz
Color Space RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0
Color Depth 8-bit, 10-bit, 12-bit (1080p@60Hz)
8-bit (4K2K@60Hz YUV4:4:4)
8-bit, 10-bit, 12-bit (4K2K@60Hz YCbCr 4:2:2 /
4:2:0)
HDMI Audio Formats LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master
Audio
ESD Protection Human-body Model: ±8kV (Air-gap discharge) ,
±4kV (Contact discharge)
Connections
Inputs Ports 4×HDMI Type A [19-pin female]
1×IR Receiver Window 1
×Micro USB
Outputs Ports 4×HDMI Type A [19-pin female]
page 06
