Orgapack OR-T 50 - 1 Technical Data; Table of Contents

ORGAPACK OR-T 50
14
12.06/WE
1 TECHNICAL DATA
TABLE OF CONTENTS
Weight 4 kg (8.8 lbs.)
Dimensions Length 400 mm (15.75“)
Width 130 mm (5“)
Height 200 mm (7.90“)
Strap tension With friction clutch fully
variable up to 2300 N
(510 lbs.) depending on strap
quality
Sealing Friction welded
Voltage Battery charger 230 V (115 V)
Battery 12 V
Emission sound pressure
levels, measurement
type A (EN ISO 11202) L
pA
83 dB (A)
Vibrations at handle
(EN ISO 8662-1) a
h,w
7,3 ms
-2
PLASTIC STRAP
Strap quality Polypropylene (PP)
Polyester (PET)
Strap width 9–10, 12–13, 15–16 or 19 mm
(
3
/
8
“,
1
/
2
“,
5
/
8
“ or
3
/
4
“)
Strap thickness 0.5–1.0 mm (.019“–.039“)
Page
1 Technical data 14
2 General information 15
2.1 Information on environmental protection 15
3 Safety instructions 16
3.1 Safety instructions for battery
charger and battery 16
4 Description 17
4.1 Design 17
4.2 Battery charger indicators 17
5 Initial operation 18
5.1 Battery charger 18
5 .2 First battery charge 18
5.3 Charging the battery 18
6 Operating instructions 19
6.1 Operating the tool 19
7 Preventive and corrective maintenance 22
7.1 Changing the battery 22
7.2 Adjusting welding time 22
7.3 Adjusting strap tension 23
7.4 Adjusting strap width 23
7.5 Cleaning the tool 24
7.6 Changing the tension wheel 24
7.7 Changing the tension shoe 24
8 Recommended spare parts 47
8.1 Parts list 47
Explosion drawing 53
DECLARATION OF AGREEMENT
According to norm:
EN ISO 12100-1, EN ISO 12100-2, EN 349,
EN 1050, EN 61000-6-1, EN 61000-6-3
CH-8953 Dietikon, 02.11.2005
Sales Manager General Manager Products
Packaging Technology: Packaging Technology:
R. Kieffer M. Binder
We take sole responsibility for declaring that the
tool OR-T 50, to which this declaration refers, is
in full compliance with the current requirements of
the guidelines laid down by the council on 22th
June 1998 (98/37/ECC), “Machine Guidelines“.
Furthermore, electrical installations are in compli-
ance with the guideline laid down by the council on
19. February 1973 (73/23/EEC) “Low Voltage Gui
delines“ and from 3th May 1989 (89/336/EEC)
“EMV Guidelines“.
