Oricom DTX4200X Quick Start Guide

4
Quick Overview of Basic Controls
Turning on the Power
PressandholdtheJogWheel.
Setting the Volume
RotatetheJogWheelclockwisetoadjustthesoundlevelforcomfortablereception.
Selecting a channel
PressJogWheelonce."CH"willappearontheLCD.
SelectthechannelbyrotatingtheJogWheel.
TurntheJogWheelclockwisetoadjustchannelUP.TurntheJogWheel
anti-clockwisetoadjustchannelDOWN.
Setting the Squelch Level
1. PressJogWheel2times.Thecurrentsquelchlevelisdisplayed.
2. SelectthesquelchlevelbyrotatingtheJogWheel.
1-Maxsensitivity(Min.squelch)
15-Min.sensitivity(Max/Tightsquelch)
Off-Squelchopen
SettingSRX(SubReceiver)Volume
1.PressJogWheel3times,then"SVL"isdisplayed.
2.RotatetheJogWheeltoadjusttheSRXvolume.
Note:
* Ifabuttonisnotpressedwithin2secondstheradiowillautomaticallyexitthesubdisplayof"VOL""CH"
"SQL"and"SVL".
PTT (Push-To-Talk) button
Beforetransmittingalwayslistenonthechanneltomakesureitisnotbeingusedbyanotheroperator.
PressingthePTTallowsaudiotobetransmitted,byspeakingacrossthefrontonthecontrollerspeaker
microphone.TXisindicatedbythelevelbarsontheLCDdisplay.
Toreceive,releasethePTTbutton.
Whentransmitting,holdtheMIC5cmfromyourmouthandspeakerclearlyinnormalvoiceacrossthefront
of the mic.
Factory Reset
Iftheradio'sdisplaylocksuporstopsfunctioningproperly,youmightneedtoresetyourUHFradio.
Caution:thisprocedureclearsalltheinformationyouhavestoredinyourUHFradio.
BeforeyouresetyourUHFradio,tryturningitoffandonagain.
IfyourUHFradioisstillnotfunctioningcorrectlyyoumayneedtoresettheUHFradio.
Toreset,pressandhold"PRI/MON"buttonandpoweron.
"Reset"willappearinthedisplay.Theradiowillthenreturntostandbymode.
