Oriental motor BLE2D200-C - Parameter Reference; I;O Signal and Function Configuration

Parameter list
41
ID Parameter name Setting range
Factory
setting
Update
*1
Alarm/information setting
1964 INFO action (Operation prohibited information (INFO-DRV))
*3
0: INFO action is not applied
1: INFO action is applied
1 A
1972 INFO action (Tripmeter information (INFO-TRIP))
*3
1973 INFO action (Odometer information (INFO-ODO))
*3
1978 INFO action (Main power supply time information (INFO-PTIME))
*3
1979 INFO action (Main power supply count information (INFO-PCOUNT))
*3
1980 INFO action (Start operation restricted mode information (INFO-DSLMTD))
*3
1981 INFO action (I/O test mode information (INFO-IOTEST))
*3
1982 INFO action (Conguration request information (INFO-CFG))
*3
1983 INFO action (Power cycling request information (INFO-RBT))
*3
Operation
2069 Slight position-keeping function selection
0: Disable
1: Enable
0 C
329 Acceleration/deceleration unit selection
0: [s / 3000 r/min]
1: [s]
0
B
330 Impact softening lter
0: No lter
1: Filter 1
2: Filter 2
0
I/O action
1819 Operation input mode selection
0: 2-Wire input mode 1
1: 3-Wire input mode 1
2: 2-Wire input mode 2
3: 2-Wire input mode 3
4: 3-Wire input mode 2
5: 3-Wire input mode 3
0 C
1817 VA detection width 1 to 400 [r/min] 200 A
I/O function selection
2112 IN0 input function selection
0: Not used, 8: ALARM-RESET
14: INFO-CLR, 16: HMI
22: TL, 25: EXT-ERROR
58: FWD (START/STOP)
59: REV (RUN/BRAKE)
64: M0, 65: M1
66: M2, 67: M3
72: STOP-MODE (CW/CCW)
73: MB-FREE
*2
, 74: H-FREE
58
C
2113 IN1 input function selection 59
2114 IN2 input function selection 72
2115 IN3 input function selection 64
2116 IN4 input function selection 65
2117 IN5 input function selection 8
2118 IN6 input function selection 73
2128
to
2134
IN0 logic level setting to IN6 logic level setting
0: Not invert
1: Invert
0
2144 OUT0 output function selection
0: Not used, 130: ALARM-OUT
134: MOVE, 135: INFO
140: TLC, 141: VA
147: SPEED-OUT, 148: DIR
147
2145 OUT1 output function selection 130
2160 OUT0 logic level setting
0: Not invert
1: Invert
0
2161 OUT1 logic level setting
I/F function
488 Operation panel editing 0: Disable, 1: Enable 1
A
489 Operation panel initial view
0: Rotation speed [r/min]
1: Load factor [%]
2: Operation data number
0
498 USB-ID enable 0: Disable, 1: Enable 1
D499 USB-ID 0 to 999,999,999 0
2555 USB-PID 0 to 31 0
*1
Timing to update
A: Update immediately (Recalculation and setup are immediately executed when the parameter is written.)
B: Update after operation stop (Recalculation and setup are executed when the operation is stopped.)
C: Update after executing conguration or turning on the power again
(Recalculation and setup are executed after the conguration is executed or the power is turned on again.)
D: Update after turning on the power again (Recalculation and setup are executed after the power is turned on again.)
*2
Only drivers for electromagnetic brake motor are available.
*3
It is enabled for drivers with software version 3.00 or later.
