Unauthorized reproduction or copying of all or part of this manual is
prohibited.
y
Oriental Motor shall not be liable whatsoever for any problems relating
to industrial property rights arising from use of any information, circuit,
equipment or device provided or referenced in this manual.
y
Characteristics, specications and dimensions are subject to change without
notice.
y
While we make every eort to oer accurate information in the manual,
we welcome your input. Should you nd unclear descriptions, errors or
omissions, please contact your nearest Oriental Motor sales oce.
y
is a registered trademark or trademark of Oriental Motor
Co., Ltd., in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2016
Published in December 2018
T
echnical Support Tel:(800)468-3982
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:00 800/22 55 66 22
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:+55-11-3266-6018
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:0800-060708
www.orientalmotor.com.tw
Singapore
Tel:1800-8420280
www.orientalmotor.com.sg
Tel:1800-806161
www.orientalmotor.com.my
Korea
Tel:080-777-2042
www.inaom.co.kr
Tel:1800-888-881
www.orientalmotor.co.th
Tel:400-820-6516
www.orientalmotor.com.cn
Tel:+91-80-41125586
www.orientalmotor.co.in
Hong Kong Branch
Tel:+852-2427-9800
Phenomenon Possible cause Remedial action
Motor is too hot.
Long continuous
operation time of the
motor.
Decrease the operation time
of the motor per session or
increase the standstill time.
Make sure that the motor case
temperature will not exceed
100 °C (212 °F).
The ACDOFF input is set
to ON.
Switch ACDOFF input to OFF.
Motor standstill current
adjustment is too high.
Lower the motor standstill
current.
TIM output does not
work.
CS input switched to ON
when TIM output is not
being output.
Switch the CS input to ON
when TIM output is being
output.
Accessories

Connection cable set
This is a cable set which includes three cables for power supply, for I/O signals,
and for motor connection.
Model:
LCS01CMK2
[0.6 m (2 ft.)]

Connection cable (for signal)
This is a shielded twisted pair cable for the driver control I/O (12 pins) that has
good noise immunity. The ground wires useful to grounding are provided at
both ends of the cable.
Model Length [m (ft.)] Conductor
CC12D005-2
0.5 (1.6)
AWG24 (0.2 mm
2
)
CC12D010-2
1 (3.3)
CC12D015-2
1.5 (4.9)
CC12D020-2
2 (6.6)

Pulse signal converter for noise immunity
This product eliminates the noise of the pulse signal, and converts the pulse
signal to the line driver type.
Model:
VCS06

CR circuit for surge suppression
This product is eective to suppress the serge which occurs in a relay contact
part. Use it to protect the contacts of the relay or switch.
Model:
EPCR1201-2

CR circuit module
This product is eective to suppress the surge which occurs in a relay contact
part. Use this product to protect the contacts of the relay or switch.
Four pieces of CR circuit for surge suppression are mounted on the compact
circuit, and this product can be installed to the DIN rail. This product can
make the wiring easily and securely since it also supports terminal block
connection.
Model:
VCS02
