Introduction
1 Introduction
■
Before use
Only qualifi ed personnel should work with the product.
The product described in this manual has been designed and manufactured for use in general industrial equipment.
Do not use for any other purpose. Oriental Motor Co., Ltd. is not responsible for any damage caused
through failure to observe this warning.
■
CE Marking
This product is affi xed the CE Marking under a self-declaration in conformity with the EMC Directive
when it is used in combination with the motorized actuators listed below.
•
Installation conditions
Driver
Motorized actuator
Overvoltage category
Ⅰ
Series name
ELS
Series,
ELF
Series,
ELX
Series,
ELC
Series,
EZS
Series
EZ
-Drive type*
Pollution degree 2
Protection against
electric shock
Class
Ⅲ
equipment
Overvoltage category
Ⅰ
Pollution degree 2
Degree of protection IP10
Protection against
electric shock
Class
Ⅲ
equipment
Degree of protection IP20
Noise level 72 dB
*Motorized linear slides for clean room use are excluded.
•
Low Voltage Directives
Because the input power supply voltage of this product is 24 VDC, it is not subject to the Low Voltage
Directive but install and connect this product as follows.
•
This product is designed and manufactured to be installed within another device. Install the product in an enclosure.
•
For the driver power supply, use a DC power supply with reinforced insulation on its primary and secondary sides.
•
EMC Directive
This product has received EMC compliance under the conditions specifi ed in “Example of actuator and driver
installation and wiring” on p.15. The conformance of your mechanical equipment to the EMC Directive will
vary depending on such factors as the control system equipment used with this product, confi guration of
electrical parts, wiring and layout. It therefore must be verifi ed through conducting EMC measures in a state
that all parts including this product have been installed in the equipment.
Applicable standards
EMI EN61000-6-4,EN61800-3,EN55011 group1 ClassA
EMS EN61000-6-2,EN61800-3
•
Machinery Directive
The motorized actuators and drivers have been designed and manufactured to be incorporated in general
industrial equipment, and a Declaration of Incorporation of Partly Completed Machinery is issued with
them according to the Machinery Directive.
Applicable standards
EN ISO 12100
■
Hazardous substances
The products do not contain the substances exceeding the restriction values of RoHS Directive (2011/65/
EU).
